Collection: Shock Travel Sensors - Race Proven Data

All Shock Travel Sensors 6 inches and larger automatically qualify for FREE SHIPPING.

Small, light weight shock sensors compatible with all EFI systems that accept a 0-5v input. These are easy to install and use. In an ideal world, we recommend three of these on each car. Two on the rear to compare and deduce information about bar setup and anti roll. The other on the left front.

Currently our 2 inch, 6 inch, 8 inch, and 10 inch shock travel sensors come with preinstalled deutsch DTM connectors. In the future all of our sensors will come with these. This makes installation much easier, particularly with our plug and play cables!

All of our shock travel sensors are 5/8 inch diameter, the perfect size to be used on the front or rear of the car. A smaller diameter sensor (although possibly cheaper) is fragile and has deflection - these are perfect.

Although we are the new kid in town when it comes to shock travel sensors, our sensors have been throughly tested. They have survived drag and drive events, high horsepower radial racing, and PDRA pro mod. They provide extremely accurate data and are built to the highest quality standards.

A picture of typical scaling is provided under each product. If you are using Holley EFI you can select the dropdown of the corresponding length racepak shock travel sensor. The wiring connections are printed on each sensor. If you really want to ball out, add a deutsch DTM connector kit and put a connector at each sensor.

If you’re chasing consistent 60-foots or trying to keep the car planted down track, this is a simple but powerful tool to add to your data arsenal.

 To answer a commonly asked question, yes our sensors work with racepak - you will either need the v net module for the length sensor you order or an available analog input.

Available Lengths: 2 inch, 4 inch, 6 inch, 8 inch, 10 inch, 12 inch. See Measurement link chart at the bottom of the home page.
